General Information

ADI Part Number

RX26-NANO

Brand Name

CDVI

Manufacturer

CDVI

Manufacturer Part Number

RX26-NANO

Packaged Quantity

1

Product Model

RX26-NANO

Product Name

1 Relay Nano Receiver

Product Series

RX26

Product Type

Nano Receiver

Weight

0.03 kg

Technical Information

Identification Method

Radio frequency

Maximum Timer Duration

30-Second

Wireless Technology

Radio Frequency

Certifications

Ingress Protection Rating

IP2X

RoHS Compliant

Compliant

TAA Compliant

No

Physical Characteristics

Application/Usage

Commercial, Garage Door, Gate, Industrial, Public Building, Roller Shutter

Color

Clear

Depth

20 mm

Height

50 mm

Material

Polycarbonate

Width

32 mm

Power Description

Input Voltage

12V AC, 12V DC, 24V AC, 24V DC

Power Source

AC, DC

Product Information

Operating Frequency

433.92MHz

Warranty

Limited Warranty

10-Year

Miscellaneous

Features

Miniature housing, Timed and pulse relay operation, Wireless transmission

CDVI RX26-NANO NANO Receiver, 1 relay
